The gas spring, also called gas strut, gas pressure springs, gas dampers or gas pressure dampers, will solve your individual requirements for opening, closing, tilting and damping flaps, tables, seats or loungers thanks to our decades of experience. They take care of the controlled movement sequence and offer the following advantages:
- Simple installation
- Compact design
- Integrated damping
- Definable spring characteristic and extension speed
Gas spring standard product range
The SUSPA standard product range of gas springs includes five different basic types 16-12, 16-1, 16-2, 16-4 and 16-6.
| TYPE | Ø TUBE (MM) | Ø PISTON ROD (MM) | STROKE MAX. (MM) | EXTENSION FORCE F1 (N) |
|---|---|---|---|---|
| 16-12 | 12 | 4 | 150 | 40 – 180 |
| 16-1 | 15 | 6 | 150 | 50 – 420 |
| 16-2 | 18.5 | 8 | 250 | 80 – 750 |
| 16-3 | 22 | 8 | 495 | 100 – 1,200 |
| 16-4 | 22 | 10 | 495 | 100 – 1,200 |
| 16-6 | 28 | 14 | 500 | 200 – 2,490 |
