Thiết bị làm mát DTT 6201
- robust: steel cover, easily paintable
- safety: 4-fold protection against condensate thanks to ideal, patented condensate management system
- service-friendly: toolless mounting and maintenance thanks to quick installation frame
- service-friendly: complete cover removable towards the front. Easily accessible filter mats (optional) and control elements in front area.
- energy efficiency: around 20 % saving on energy thanks to the use of more effective, lighter components
- energy efficiency: optional Multi Controller with energy-saving operation mode
- design and colour matching: perfect mixture of functionality and design
- available in stainless steel
| DTT 6201 | ||||
|---|---|---|---|---|
| Rated voltage ±10 % | AC 50/60 Hz | AC 60 Hz | ||
| 400 V 2~¹ | 230 V | 115 V | ||
| Cooling performance according to EN 14511 |
A35/A35 | 1000 / 1080 W | ||
| A35/A50 | 600 / 640 W | |||
| Ambient temperature | +15 … +55 °C / +59 … +131 °F | |||
| Degrees of protection according to EN 60529 |
IP 54 | towards the electrical enclosure if used as intended by the manufacturer |
||
| IP 34 | towards the surroundings if used as intended by the manufacturer |
|||
| Condensate management | integrated condensate evaporation system with safety overflow | |||
Suitable for various supply voltages. 400 V units can be operated at 460 V by reconnecting a different pin on the transformer (see technical specific data sheet).
Further technical details, performance curves and dimensions can be found in the download section on this page under product sheet.
Further technical details and dimensions can be found in the download section on this page under product sheet.
