EP080F+MOD

Electr. 2-way PI-CCV EPIV, AC/DC 24 V, BACnet MS/TP, Modbus RTU, MP-Bus, 2…10 V, DN 80, Flange, PN 16, ps 1600 kPa, V’nom 11 l/s, Fluid temperature -10…120°C [14…248°F]

Electronic Pressure Independence Control Valve (ePICV):
– DN80, Nominal Flow: 11.33 l/s
– Control: Modulating or ON/OFF
– Nominal voltage: AC/DC 24 V
– Control modulating: DC 2 … 10 V
– Position/Flow feedback: DC 2 … 10 V
– Communicative control: BACnet MS/TP, Modbus RTU
– Running time: 90s/90°
– Materials: Flow measuring pipe: EN-GJL-250 (GG 25), with protective paint, Closing element: stainless steel AISI 316, Stem seal: EPDM
– Leakage rate: Zero leakage, Class A (EN 12266-1)
– Flow Sensor: Ultrasonic volumetric flow measurement, +/-2% accuracy
– Servicing: maintenance-free, 5 years warranty
