M6C-5S8XH51-T003 | Nidec Avtron M6C-5S8XH51-T003 | Encoder M6C-5S8XH51-T003

PART NUMBER: M6C-5S8XH51-T003
DESCRIPTION: M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
COMMENT: This is a drop in replacement for the obsolete model M6-5S3XH51-T003
DESCRIPTION: OPTION:
Hollow Shaft Bore Size  5 – 1-1/8 inch Hollow Shaft
Mounting :S – Standard End-of-Shaft Mounting
Line Driver :8 – 5-24V In/Out Protected Line Driver
Left Output : X – No Left Output
Right Output :H – High Res.
Base PPR :51 – 512 PPR
Marker :- – No Marker
Connector Options :T – Terminal Block
Modifications : 003 – Includes B28390 Torque Arm Kit
(Drive Motor Incremental Encoder, 1024Ppr, 12-24Vde, Imax=160Ma, Pmax=4.48W Model: M6-5S3XH51-T003)
